Core Strengths

The V180 agricultural drone is a breakthrough platform with a maximum payload of 180 kg, pushing operational efficiency to a new level. It supports multiple mission scenarios—including spraying and lifting—delivering a unique, intelligent operating experience.

180 kg

Max Payload

Ultra-Fast charging

35 L/min

Max Spray Flow Rate

360°

Omnidirectional Obstacle Avoidance Radar + Terrain-Following Radar + LiDAR

HD Remote Controller

Powerful Performance

350 A high-current ESC for fast motor response

250 kg/min

Max Discharge Rate

35 L/min

Max Spray Flow Rate

180 kg

Max Payload

Ultra-Fast charging

HD Remote Controller

Powerful Performance

350 A high-current ESC for fast motor response

360°

Omnidirectional Obstacle Avoidance Radar + Terrain-Following Radar + LiDAR

250 kg/min

Max Discharge Rate

Intelligent Lifting,
Safe & Worry-Free

The ideal solution for the “last mile” — and the toughest mile.

Intelligent Anti-Swing

Integrates core technologies of “tri-directional force sensor + intelligent algorithm + attitude adjustment,” enabling automatic attitude corrections during flight to suppress swinging and ensure safe, stable operations.

Real-Time Weighing

By integrating force load sensors with intelligent algorithms, it delivers precise real-time weight monitoring and dynamic analysis, effectively preventing overload risks and providing data traceability throughout the entire operation.

Emergency Load Release

Equipped with an emergency quick-release mechanism. Triggered remotely via the controller, it rapidly separates the load to prioritize protecting the aircraft, reducing crash risk and losses.

A–B Waypoint Autonomous Operation

With precise point-to-point route planning, it reduces labor demands and standardizes and automates workflows.

Automatic Hook Release

Equipped with an automatic release hook.

Agriculture & Forestry

Power & Energy

Construction & Infrastructure

Emergency Firefighting

Fully Adaptable to Multiple Scenarios

Suitable for scenarios such as forestry material transportation, emergency rescue supply, high-altitude building material delivery, and mountainous area logistics

Efficient Spraying,
Large-Scale Operation

Large Water Volume, Large Water Tank, Fine Spray Droplets, Rear-Mounted Four-Nozzle Layout, Improve Field

150 L

Spray Tank
13 m

Max Spray Width
4 Nozzles

Standard Configuration
50–500 μm

Centrifugal Atomization Droplet Size

High-Efficiency Spreading System

Designed for fast, uniform, and reliable spreading across a wide range of agricultural applications.

200 L

Spreading Tank
250 kg/min

Max Discharge Rate
12 m

Max Spreading Width
0.5 -10 mm

Particle Diameter

Powerful Performance,
Stable & Reliable

Dynamic Structure

Powertrain Architecture Adopts a split-structure design with a 4-axis, 8-propeller layout and carbon-fiber propellers. The simple yet highly stable structure delivers comprehensive improvements in performance, efficiency, and safety redundancy.

Overwhelming Power

Max Total Thrust ≥500 kg
Full-Payload Efficiency

The lightweight design reduces energy consumption and improves energy conversion efficiency under full load.
Operational Stability

4-axis 8-propeller layout + high-strength fuselage structure, maintaining stable flight even under complex wind conditions (with a wind resistance rating of level 6) and in high-drop scenarios
Response Speed

Powered by a 350A high-current ESC for fast motor response

Split-Structure Design

The flight platform and mission system are separable, enabling fast switching between sprayingand lifting as needed.
70-inch Carbon-Fiber Propeller

Made of carbon fiber for higher rigidity and lower weight, with strong resistance to deformation at high temperatures.
Industry-First Automotive-Grade Flat-Wire Motor

Powerful, stable, and reliable—delivering faster response with ESC response time <1 μs.

Energy System,
Continuous Operations

The V180 pairs with two high-capacity smart cooling batteries and supports ultra-fast charging. Its grille-based cooling design delivers rapid heat dissipation while ensuring safety, enabling sustained high-intensity operations.

High-Capacity Battery

38 Ah

Battery Capacity
>700%

Heat Dissipation Area
16 mins

Flight Time
Grille-Based Cooling Design

Smart Cooling Charger (Three-Phase Power)

12 kW

Ultra-Fast Charging
10 min

25% to 95% Charge

High-Capacity Battery Smart Cooling Charger (Three-Phase Power)

Perception System,Safety Assured

By integrating a 360° omnidirectional obstacle avoidance radar, terrain-following radar, and optional LiDAR, the V180 significantly enhances obstacle avoidance, terrain following, and high-precision positioning-improving environmental adaptability and operational safety.

Beyond-Visual-Range Assurance

Radar and video transmission work together for an effective detection range of >60 m, enhancing situational awareness and preventing collisions.

Beyond-Visual-Range Assurance

Radar and video transmission work together for an effective detection range of >60 m, enhancing situational awareness and preventing collisions.

Beyond-Visual-Range Assurance

Radar and video transmission work together for an effective detection range of >60 m, enhancing situational awareness and preventing collisions.

Beyond-Visual-Range Assurance

Radar and video transmission work together for an effective detection range of >60 m, enhancing situational awareness and preventing collisions.

Powerful Performance, Stable & Reliable

The V180 drone integrates dedicated dual-band (2.4/5.8GHz) image transmission with 4G public network connectivity. By combining an FPV perspective and dual-remote cooperative control, it enables stable, continuous high-definition visual operation for reliable beyond-visual-line-of-sight (BVLOS) missions.

Remote Controller

The multifunction intelligent remote controller uses a dual-battery design and features an 8-inch HD display and a high-performance processor. With rich software capabilities and dedicated shortcut keys, it significantly improves control stability, convenience, and mission duration.
